FP10 Lafayete

FP10 Lafayete Description

Lafayette, the French officer and hero of the American Revolution, inspired us to create our newest high efficiency fireplace. As the great general, Valcourt used its tactical skills in developing the Lafayette fireplace so it provides home heating with superb efficiency and elegance. Further to offering a revolutionary look, Lafayette meets the highest EPA emissions requirements, making it the fireplace of choice for the new generation of consumers who want to use wood as a renewable and clean source of heat.

  • Model # : FP10
  • High-efficiency EPA certified fireplace
  • Recommended Heating Area (sq. ft.) : 500 - 2100
  • Premium quality convection blower included (CFM) : 120
  • Color : Metallic black
  • Glass air-wash system
  • Efficiency : 77%
  • Emissions : 4.4 g/h
  • Stainless-steel secondary-air system improving gas combustion
  • Burn rate : < 1kg/h (< 2.2 lb/h)
  • Burn time : 8 - 9 h
  • Moulded refractory bricks
  • Recommended connector pipe diameter : 6" / 7"
  • Tested and listed as per applicable standards by : An accredited laboratory

Firebox – dimension (Width)20 7/8"
Firebox – dimension (Depth)13"
Overall dimension (Height)47 1/8"
Overall dimension (Width)37 7/8"
Overall dimension (Width)29 5/8"
Door opening dimensions (Height))10 3/4"
Door opening dimensions (Width)25 1/2"
Energetic power75,000 BTU/h
Maximum output - EPA test wood30,450 BTU/h
Minimum chimney height (feet)15
Maximum log length21"
Weight391 lb (177 kg)
391 lb (177 kg)Over width
Glass surface – dimensions (Width X Height)12 5/8" x 24 3/8"
Type of chimney2100 °F (ULC S629/UL 103 HT)
Product TypeWood
Door TypeSingle, glass with steel frame
Glass TypeCeramic Glass
Firebox volume (cu. ft.)2.5
Centre line of flue outlet to the back10 1/8"
Centre line of flue outlet to the side18 7/8"
Canadian standard (emissions)CSA B415.1
USA standard (emissions)EPA Method 28
Canadian standard (safety)ULC S610
USA standard (safety)UL 127
Recommended heating area (sq. ft.)500 - 2100
Emissions4.4 g/h
Flue outlet diameter6"
Burn Rate< 1kg/h (< 2.2 lb/h)
Burn Time8 - 9 h
Recommended connector pipe diameter6 / 7"
WarrantyLimited lifetime
Tested and listed as per applicable standards byAn accredited laboratory
