FP9 Versailles

FP9 Versailles Description

At Valcourt, we think of our newly introduced Versailles fireplace as the “Duchess of all fireplace heaters".

In fact, consider just how much heat this fireplace will generate and you will understand the nickname. The heat is “tremendous" and so is the fireplace itself with a ceramic glass door the size of which has never been seen in an EPA rated fireplace. With the Versailles fireplace, think glass door size and think...HEAT. Furthermore, like the FP8, the FP9 can be connected to your furnace’s ducting system*.

The palace at Versailles is a building of incredible beauty and grandeur. It has been home to the most influential people in French aristocracy over many centuries. We believe this palatial fireplace will warm both your heart and your home. Our Versailles zero clearance heater is truly a “Duchess among fireplaces".

*Certain local building codes may impose restrictions.

  • Model # : FP9BO
  • High-efficiency EPA certified fireplace
  • Recommended Heating Area (sq. ft.) : 500 - 2,800
  • Color : Metallic black
  • Glass air-wash system
  • Efficiency : 75%
  • Emissions : 4.2 g/h
  • Stainless-steel secondary-air system improving gas combustion
  • Burn rate : < 1kg/h (< 2.2 lb/h)
  • Cast iron andirons
  • Moulded refractory bricks
  • Recommended connector pipe diameter : 8"
  • Tested and listed as per applicable standards by : An accredited laboratory

Firebox – dimension (Width)22 1/2"
Firebox – dimension (Depth)13 1/4"
Overall dimension (Height)43 1/2"
Overall dimension (Width)43 7/8"
Overall dimension (Depth)28 1/4"
Door opening dimensions (Height)13 1/4"
Door opening dimensions (Width)30"
Energetic power120,000 BTH/h
Maximum output - EPA test wood69,500 BTH/h
Minimum chimney height (feet)15
Maximum log length18"
Weight537 lb (244 kg)
Log positioningOver width
Type of chimney2100 °F (ULC S629/UL 103 HT)
Product typeWood
Door typeDouble, glass with cast iron frame
Glass typeCeramic glass
Firebox volume (cu. ft.)3.5
Top (measured from the floor)84"
Centre line of flue outlet to the back9 3/8"
Centre line of flue outlet to the side22"
Combustible top mantle to unit12"
Canadian standard (emissions)CSA B415.1
USA standard (emissions)EPA Method 28
Canadian standard (safety)ULC S610
USA standard (safety)UL 127
Glass surface – dimensions (Width X Height)16 1/2" x 26 3/4"
Recommended heating area (sq. ft.)500 - 2,800
Emissions4.2 g/h
Flue outlet diameter8"
Burn rate< 1kg/h (< 2.2 lb/h)
Recommended connector pipe diameter8"
WarrantyLimited lifetime
Tested and listed as per applicable standards byAn accredited laboratory
